EC Grade 1350 Aluminum Rod

EC Grade 1350 Aluminum Rod is a high-conductivity aluminum rod manufactured from high-purity aluminum for electrical conductor and cable applications. Featuring excellent conductivity, smooth surface quality, and outstanding drawing performance, it is widely used in AAC, aluminum wire, and power cable manufacturing. Ampo Cable provides reliable supply, customized specifications, and international standard production for global cable manufacturers and distributors.

Description

EC Grade 1350 Aluminum Rod is a high-purity electrical conductor material manufactured from premium aluminum with a minimum purity of 99.5%. Designed specifically for electrical applications, it offers outstanding electrical conductivity, excellent ductility, and superior wire drawing performance.

It is widely used as the primary raw material for manufacturing aluminum wires, AAC conductors, ACSR conductors, power cable conductors, transformer windings, and various electrical components.

Manufactured through advanced continuous casting and rolling (CCR) technology, our EC Grade 1350 Aluminum Rod features a smooth surface finish, stable mechanical properties, and consistent dimensional accuracy. It is suitable for high-speed wire drawing operations and meets the requirements of international electrical conductor standards.

Ampo Cable supplies EC Grade 1350 Aluminum Rod in various diameters and coil weights, with OEM and customized production available according to customer specifications.

Technical Data

Item	Specification
Product Name	EC Grade 1350 Aluminum Rod
Material	EC Grade 1350 Aluminum
Aluminum Purity	≥99.5%
Conductivity	≥61.0% IACS
Electrical Resistivity	≤0.02826 Ω·mm²/m (20°C)
Density	2.70 g/cm³
Tensile Strength	95–125 MPa
Elongation	≥10%
Standard Diameter	9.5 mm
Optional Diameter	12 mm / 15 mm / Customized
Coil Weight	1.5–2.5 MT
Surface Finish	Bright & Smooth
Production Process	Continuous Casting & Rolling (CCR)
Service	OEM / ODM
Certificate	ISO 9001 / SGS

Available Sizes

Diameter	Coil Weight	Application
9.5 mm	2 MT	Aluminum Wire Drawing
12 mm	2 MT	Power Cable Conductors
15 mm	Customized	Industrial Electrical Applications
Customized	Customized	OEM Projects

Production inspection

Packaging & Shipping

Certificates

FAQ

What is EC Grade 1350 Aluminum Rod?

EC Grade 1350 Aluminum Rod is a high-purity electrical aluminum rod with excellent conductivity, widely used in conductor and cable manufacturing.

What is the standard diameter?

The most common diameter is 9.5 mm, while customized diameters are also available.

Can you provide customized specifications?

Yes. We provide OEM and ODM services based on customer requirements.

Which standards do you follow?

ASTM, IEC, BS EN, DIN, and customized international specifications.

Do you provide Mill Test Certificates?

Yes. MTC, SGS inspection reports, and third-party inspection services are available.
