BS 7629-1 600/1000V SR Insulated Flexible Fire Resistant Control Cable
BS 7629-1 600/1000V SR Insulated Flexible Fire Resistant Control Cable is a high-capacity fire-resistant control cable for power supply and signal transmission in indoor, outdoor and wet environments. It combines copper conductors, fire-resistant silicone-rubber insulation and an LSZH outer sheath, with conductor classes selected according to cross section.
PRODUCT OVERVIEW
The product is based on a BS 7629-1 design concept adapted for 600/1000V applications. Conductors up to 10 mm² are plain annealed copper stranded to IEC/EN 60228 Class 2, while sections above 10 mm² use flexible IEC/EN 60228 Class 5 conductors. The cores are insulated with fire-resistant silicone-rubber compound type EI2, cabled together with suitable non-hygroscopic fillers and finished with an LSZH outer sheath.
This construction is intended for fixed laying in free air, pipe or conduit, on masonry and metal structures, or suspended installations. The cable is specifically aimed at environments where, in the event of fire, smoke, toxic or corrosive gases present a serious risk to people or could damage facilities, equipment or goods. Typical service duties include emergency exits, alarm signals, smoke or gas warning systems and escalator circuits.
KEY FEATURES
- Basic design adapted from BS 7629-1.
- Rated voltage: 600/1000V.
- Copper conductors to IEC/EN 60228: Class 2 up to 10 mm²; Class 5 above 10 mm².
- Fire-resistant silicone-rubber insulation type EI2.
- Thermoplastic LSZH outer sheath type LTS3; thermosetting SW2-SW4 can be offered.
- Designed for power supply and signal transmission.
- Suitable for indoor, outdoor and wet environments.
- Fixed installation in free air, pipe, conduit, masonry, metal structures or suspended routes.
- Available in 2-, 3-, 4- and 5-core configurations.
- Conductor sizes listed from 1.5 mm² to 16 mm².
- Operating temperature: -30°C to +90°C.
- Minimum bending radius: 6 × overall diameter.
CABLE CONSTRUCTION
Voltage Rating | 600/1000V |
Conductor ≤10 mm² | Plain annealed copper, stranded IEC/EN 60228 Class 2 |
Conductor >10 mm² | Plain annealed copper, flexible IEC/EN 60228 Class 5 |
Insulation | Fire-resistant silicone-rubber compound type EI2 |
Cabling | Cores cabled in concentric layers with suitable non-hygroscopic fillers |
Outer Sheath | Thermoplastic LSZH LTS3; optional thermosetting LSZH SW2-SW4 |
Sheath Colour | Red; other colours on request |
STANDARD BASIS & FIRE PERFORMANCE
The product data states that the basic design is adapted from BS 7629-1. Its fire-performance references cover circuit integrity, mechanical shock, water spray, flame propagation, halogen content, smoke emission and toxic-gas performance.
Performance | Referenced Test / Standard |
Circuit integrity | IEC 60331-21; BS 6387 CWZ; DIN VDE 0472-814 (FE180); BS 8434-1 (30 min); BS 5839-1 Clause 26 2d; CEI 20-36/2-1; SS229-1; NBN C 30-004 (F3); NF C32-070-2.3 (CR1) |
Circuit integrity with mechanical shock | EN 50200 (PH60); CEI 20-36/4-0 |
Circuit integrity with mechanical shock & water spray | EN 50200 Annex E |
System circuit integrity | DIN 4102-12, E30 depending on lay system |
Flame retardance – single vertical wire | EN/IEC/BS EN 60332-1-2 and listed equivalents |
Reduced fire propagation – bundled cables | EN/IEC/BS EN 60332-3-24 (Cat. C) and listed equivalents |
Halogen free | IEC 60754-1 and listed equivalents |
No corrosive gas emission | IEC 60754-2 and listed equivalents |
Minimum smoke emission | IEC 61034-1&2 and listed equivalents |
No toxic gases | NES 02-713; NF C 20-454 |
WHY THE CONDUCTOR CLASS CHANGES WITH SIZE
The listed conductor construction changes at the larger cross sections. Up to 10 mm², the product uses Class 2 stranded copper conductors; above 10 mm², the brochure specifies Class 5 flexible conductors. This allows the larger cable sizes to retain improved handling and installation flexibility as conductor diameter and cable mass increase.
PRODUCT APPLICATIONS
- Emergency-exit supply circuits.
- Alarm signal circuits.
- Smoke or gas warning systems.
- Escalator feeding circuits.
- Power supply and signal transmission in indoor or outdoor installations.
- Wet-environment fixed installations.
- Fixed laying in free air, pipe or conduit.
- Installation on masonry and metal structures or suspended routes.
- Locations where reduced smoke, toxic gas and corrosive gas emissions are important during fire.
SELECTION GUIDANCE
Selection should consider voltage, conductor cross section, conductor class, number of cores, installation method, route length, fire-performance requirement and environmental conditions. The broad 1.5-16 mm² range allows the same cable family to cover small control circuits and higher-current emergency-supply duties.
- Confirm 600/1000V system voltage.
- Choose the required number of cores.
- Select conductor size from the listed 1.5-16 mm² range.
- Check whether the selected size uses Class 2 or Class 5 conductor construction.
- Confirm whether the installation is indoor, outdoor or in a wet environment.
- Check current-carrying capacity for the actual reference installation method.
- Check voltage drop for the circuit length and current.
- Confirm required PH60, mechanical-shock or water-spray fire performance where applicable.
- Confirm sheath colour, cable code, drum length and required test documentation in the RFQ.
The listed construction range includes 2-, 3-, 4- and 5-core cables with conductor sizes from 1.5 mm² to 16 mm². Cable code references include FFX400 1SZ1-R(PH60) and FFX400 1SZ1-F(PH60) depending on the listed construction.
| Cable Code | No. of Cores × Cross Section | Insulation mm | Sheath mm | Overall Diameter mm | Approx. Weight kg/km |
|---|---|---|---|---|---|
| FFX400 1SZ1-R(PH60) | 2x1.5 | 1.0 | 1.2 | 9.2 | 124 |
| FFX400 1SZ1-R(PH60) | 2x2.5 | 1.1 | 1.3 | 10.0 | 155 |
| FFX400 1SZ1-R(PH60) | 2x4.0 | 1.1 | 1.4 | 11.2 | 207 |
| FFX400 1SZ1-R(PH60) | 2x6.0 | 1.1 | 1.5 | 13.1 | 298 |
| FFX400 1SZ1-R(PH60) | 2x10 | 1.1 | 1.6 | 15.9 | 441 |
| FFX400 1SZ1-R(PH60) | 2x16 | 1.1 | 1.7 | 17.4 | 602 |
| FFX400 1SZ1-R(PH60) | 3x1.5 | 1.0 | 1.2 | 9.8 | 148 |
| FFX400 1SZ1-R(PH60) | 3x2.5 | 1.1 | 1.3 | 10.6 | 188 |
| FFX400 1SZ1-R(PH60) | 3x4.0 | 1.1 | 1.4 | 12.1 | 263 |
| FFX400 1SZ1-R(PH60) | 3x6.0 | 1.1 | 1.5 | 14.4 | 372 |
| FFX400 1SZ1-R(PH60) | 3x10 | 1.1 | 1.6 | 16.8 | 541 |
| FFX400 1SZ1-R(PH60) | 3x16 | 1.1 | 1.7 | 19.4 | 777 |
| FFX400 1SZ1-R(PH60) | 4x1.5 | 1.0 | 1.3 | 10.6 | 176 |
| FFX400 1SZ1-R(PH60) | 4x2.5 | 1.1 | 1.4 | 11.5 | 228 |
| FFX400 1SZ1-R(PH60) | 4x4.0 | 1.1 | 1.5 | 13.6 | 332 |
| FFX400 1SZ1-R(PH60) | 4x6.0 | 1.1 | 1.6 | 11.5 | 214 |
| FFX400 1SZ1-R(PH60) | 4x10 | 1.1 | 1.7 | 18.5 | 680 |
| FFX400 1SZ1-R(PH60) | 4x16 | 1.1 | 1.8 | 21.2 | 973 |
| FFX400 1SZ1-R(PH60) | 5x2.5 | 1.1 | 1.4 | 12.6 | 266 |
| FFX400 1SZ1-R(PH60) | 5x4.0 | 1.1 | 1.5 | 14.5 | 399 |
| FFX400 1SZ1-R(PH60) | 5x6.0 | 1.1 | 1.6 | 17.6 | 576 |
| FFX400 1SZ1-R(PH60) | 5x10 | 1.1 | 1.7 | 20.5 | 850 |
| FFX400 1SZ1-R(PH60) | 5x16 | 1.1 | 1.8 | 23.3 | 1202 |
Request the Complete Data Sheet
From Production to Delivery
From raw material preparation to final shipmen, every stage is caretuly controled to ensure consistent conductor quality, reliable pertormance,and sae delivery. Our roduction,
inspection, packaging, and logistics processes are managed in accordance with applicable standards and project requirements.
Production
Copper conductors are prepared in the required Class 2 or Class 5 construction, insulated with fire-resistant silicone rubber, cabled with suitable fillers and finished with the specified LSZH sheath.
Inspection
Inspection focuses on conductor construction, insulation quality, core identification, sheath condition, dielectric test, insulation resistance, dimensions and required fire-performance documentation.
Packaging
Finished cables are wound onto suitable drums according to ordered size and length. Cable ends are secured and protected, and drum identification can include cable code, voltage, conductor size, core count, length and project reference.
Shipping
Before shipment, cable drums and accompanying technical documents are checked against the purchase order and packing list. Test records, inspection documents and cable identification can be prepared according to project requirements.
Frequently Asked Questions
What conductor classes are used?
Class 2 stranded copper up to 10 mm² and Class 5 flexible copper above 10 mm².
What insulation is used?
Fire-resistant silicone-rubber compound type EI2.
Is the cable suitable for outdoor or wet environments?
Yes. The application section states indoor or outdoor use, including wet environments.
What conductor sizes are listed?
1.5, 2.5, 4, 6, 10 and 16 mm².
What is the dielectric test voltage?
3500 V r.m.s. for 5 minutes, core-to-core.
